You don't have permission to access /service-repair/ Does anybody have any experience with this particular vacuum or series and can offer me any more explicit things to check than just "is the belt on the brush cylinder" and the like. I'm under the impression my father in law was "helping" me with this particular vacuum and I wasn't there when he did so. It has a floor height setting, and a setting for brush control, but that's not changing it's indicator and changing the floor height doesn't make any difference (neither does lifting the vacuum off the floor. I have tried what I know to be the basics, but feel free to go along behind me and suggest the dumb stuff, I'll respond as I am able. This question exists because it has historical significance, but it is not considered a good, on-topic question for this site, so please do not use it as evidence that you can ask similar questions here. This question and its answers are frozen and cannot be changed. More info: help center.

I worked on vacuums for years, though I am not familiar with this particular model. Still, there are only a few things that can cause a roller not to spin: The plate above the roller, or the housing above the roller must be able to be removed to get access to the belt/roller. You'll have to figure out which. There are usually plastic clips/tabs that are indicated (usually with an arrow or something). It may have a couple of screws. They should be very visible. Once you have access to the roller, pull it out of the housing. You may have to flex the housing to achieve this. That is ok and expected. Flexing over about 1/8" is a problem, so don't go too far. Most of the time the roller should just slide out. It probably has a lot of gunk/dust/hair around it, so you may have to finagle it out. The belt is usually a flat belt (though sometimes they are round). It runs from the roller to a metal post sticking out of the motor. If it is a flat belt, it will attach to the roller and motor on one side.

If it is a round belt it will likely attach in the middle. At this point the roller should be out of the housing. Hot Tub Covers CyprusSee if the roller spins easily by holding the end caps. Growing Weed Without Uv LightsIf it does not, the bearings are bad. Cheap Siberian Husky Puppies For Sale In WashingtonSometimes the ends will screw off and you can see if hair has wrapped around the bearing. If so, you may be able to remove the hair and it will function again. If not, you need a new roller. If the roller works, make sure the motor pulley spins. Locate the motor pulley/post. Spin by hand or run the vacuum and carefully determine that the motor pulley is spinning. If you can hear the motor, the pulley is almost definitely spinning, but not in all cases.

If the motor spins and the roller bearings are good, all you need is a belt. Make sure you have the right belt. They will sometimes be surprisingly small. Loop the belt around the motor pulley first and then the roller, while the roller is out of the housing. Plant the non-belt end of the roller into the housing and, while holding that end in the housing with one hand, leverage the other end into the housing while stretching the belt. This can be anywhere from moderately to very difficult. Lastly, spin the roller by hand making sure the belt is not caught in the housing somewhere. This almost always happens. If you spin by hand it will naturally center out on the pulley. If you don't do this and put the vacuum back together and start the motor, it will burn through the belt very fast. Lastly, it sounds like you may be having some problems with the height adjustment not working correctly. I can't really tell by reading your post. If so, your father-in-law may have gotten a little overzealous with the screwdriver and taken apart part of the height adjustment linkage.

Vacuums rarely need a lot taken apart to change a belt. If he went too far and you can't figure out how to get it back together, you may need to take it to a repair shop. The edges of your cylinder which the brush is connected to may have hair or threads wrapped around the axle preventing it from spinning. Are you able to easily rotate the cylinder yourself with your hand while the vacuum is on? If you are able to rotate it easily with your hand, then there may be a mechanical problem with the part of the motor that turns the belt and you'll need to get the vacuum repaired (although it may be cost effective to just replace it with a new one). My daughters brush stopped working--I thought it was the belt--took the bottom plate off to fix the belt, and both belts were intact. Noticed the suction tube was totally clogged--cleaned it out(there was alot there), and the brush worked fine. I don't understand this, but that is all I did. Does the roller brush turn freely? If it doesn't, pull it out and check to see if the brush bearings are turning in the roller brush.

Second, make sure both belts are in place and not broken. Another problem: maybe the clutch itself is bad.Browse other questions tagged tools or ask your own question. Published on Sep 10, 2012 The Hoover Portapower Vacuum is one of the best canister vacuums you'll ever use. This vacuum has major suction power and will last you forever if you follow these few tips. The Portapower vacuum is a cleaning tool that should be in everyone's cleaning supplies closet! This is vacuum is one of the top commercial vacuums used by residential maid companies around the world. Easy to fix and will last you forever, ! The Hoover Portapower Vacuum is hands down the best canisterVacuum you’ll ever use!Look at it sucking to the wall, such power! This is why it’s the topvacuum for cleaning companies!Use the Vacuum to:Vacuum FloorsVacuum UpholsteryVacuum CarsVacuum StairsDust BlindsDust BaseboardsVacuum in tight placesSo Much More The Following are Several ways to get Peak Performance andKeep this vacuum in great shape!

Always Wrap your Vacuum Cord like this!Never wrap your vacuum cord in a figure eight. This damages the cord and will cause you to have toreplace the vacuum cord due to damage! Wrap It in a circle and attach with the provided strap asshown! If your Vacuum Cord does becometangled, extend the cord in an openroom all the way out. Swing thecord in a circular motion from theback as shown by the arrow untilthe cord becomes straight andsmooth. Take the vacuum cord andwrap in a circle now! The Hoover Portapowerhas the best power whenthe vacuum hose issecurely attached. If yourhose ever becomes looseafter years of use, take apiece of thin cardboardwrap over the top of thehose as shown on leftand attach the hose asnormal to the vacuum asshown on right. You’llnotice its tough to attachbut it creates a great sealfor extra SUCTIONPOWER! Vacuum Suddenly Lost Suction 1) Make sure bag is empty2) Detach hose turn on Vacuum and put your hand up againstthe hole. See if you can pull the vacuum towards you, if soSuction on Vacuum is fine.

So Next3) Attach hose to back of vacuum as shown on Left. Turn on thevacuum and you’ll probably blow something out (maybe acaught sock….) Before doing this, make sure you have your dooropen and hose pointing outside, as dust will come blowing outalso.4) Check the wand make sure nothing caught5) Might have to stick a pole through hose if something isjammed (last resort)6 ) You might need a new hose. If the hose has tiny holes it willprevent the vacuum from having top suction power!Nice Hose – 2 years Old – Look at next slide to see why it looksbrand NEW! Never Store your Canister Vacuum with the Hose attached to the vacuum as shown. This puts unnecessary stress on theYikes don’t hose. This can cause your hose to getstore hoseattached holes easier and begins to ware outEVER! the area you attach the hose to. If vacuuming corners or furniture,as mentioned in previous slidedon’t pull the hose more thanneeded. Sometimes instead ofattaching tools to the wand, youmight find it easier to attach tothe hose for more flexibility.
